Baumer
12 products, 312 attributes mapped across 1 ETIM class. 67% coverage from public catalogs and spec sheets alone.
Products12
Scanning principleReflection system
Type of analogy output4 mA ... 20 mA
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.2 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Light dot3.14 mm2
Max. output current100 mA
Measuring range length100-500 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output0 V ... 10 V / 0 mA ... 20 mA
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.12 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Light dot3.14 mm2
Max. output current100 mA
Measuring range length200-1000 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output4 mA ... 20 mA
Type of electric connectionConnector M8
Supply voltage12-28 V
Width sensor12.4 mm
Height of sensor37 mm
Length of sensor34.5 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.002 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Light dot0.2 mm2
Max. output current100 mA
Measuring range length16-26 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output4 mA ... 20 mA
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.01 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current100 mA
Measuring range length30-50 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output0 V ... 10 V
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.004 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current100 mA
Measuring range length30-70 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output0 V ... 10 V / 0 mA ... 20 mA
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.004 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current100 mA
Measuring range length30-70 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output0 V ... 10 V
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.05 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current100 mA
Measuring range length30-130 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output4 mA ... 20 mA
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.05 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current100 mA
Measuring range length30-130 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output0 V ... 10 V / 0 mA ... 20 mA
Type of electric connectionConnector M12
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.1 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current100 mA
Measuring range length50-300 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature0-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output0 V ... 10 V / 0 mA ... 20 mA
Type of electric connectionCable
Type of switching outputPNP
Supply voltage12-28 V
Width sensor20.6 mm
Height of sensor65 mm
Length of sensor50 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution0.01 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current100 mA
Measuring range length50-300 mm
Measuring principle for optical distance measurementTriangulation
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature-20-60 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialZinc
Scanning principleReflection system
Type of analogy output4 mA ... 20 mA
Type of electric connectionConnector M12
Supply voltage15-28 V
Width sensor25.4 mm
Height of sensor66 mm
Length of sensor51 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution1.3 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current250 mA
Measuring range length200-4000 mm
Measuring principle for optical distance measurementLight delay time
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature-25-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialAluminium
Scanning principleReflection system
Type of analogy output4 mA ... 20 mA
Type of electric connectionConnector M12
Supply voltage15-28 V
Width sensor25.4 mm
Height of sensor66 mm
Length of sensor51 mm
Setting procedureTeach-In
Explosion safety category for gasNone
Explosion safety category for dustNone
Construction type housingCuboid
Geometrical resolution5 mm
Laser protection classClass 2
Type of lightLaser diode, red light
Max. output current250 mA
Measuring range length200-13000 mm
Measuring principle for optical distance measurementLight delay time
Standard for interfacesAnalogue
Degree of protection (IP)IP67
Voltage typeDC
Ambient temperature-25-50 C
Pre failure noticeYes
Material of optical surfaceGlass
With time functionNo
Housing materialAluminium
