SICK

11 products, 581 attributes mapped across 3 ETIM classes. 80% coverage from public catalogs and spec sheets alone.

Download BMEcat XML Get this for your catalog

Products11

Operating distance20-350 mm

Pre failure noticeNo

With time functionNo

Max. switching distance350 mm

Max. output current100 mA

With reflectorNo

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionCable

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Response time0.33 ms

Switching frequency1500 Hz

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classNone

Wavelength of the sensor640 nm

Type of lightPolarity free red light

Material of cable sheathPolyvinyl chloride (PVC)

With restart blockageNo

Suitable for safety functionsNo

Degree of protection (IP)IP67

Ambient temperature-40-60 °C

Rated control supply voltage DC10-30 V

Operating distance30-175 mm

Pre failure noticeNo

With time functionNo

Max. switching distance175 mm

Max. output current100 mA

With reflectorNo

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Response time0.33 ms

Switching frequency1500 Hz

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classNone

Wavelength of the sensor640 nm

Type of lightPolarity free red light

Light dot3.14 mm²

With restart blockageNo

Suitable for safety functionsNo

Degree of protection (IP)IP67

Ambient temperature-40-60 °C

Rated control supply voltage DC10-30 V

Operating distance30-200 mm

Pre failure noticeNo

With time functionNo

Max. switching distance200 mm

Max. output current100 mA

With reflectorNo

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP/NPN

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15 mm

Height of sensor49 mm

Length of sensor41.5 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Response time0.2 ms

Switching frequency2500 Hz

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classClass 2

Wavelength of the sensor650 nm

Type of lightLaser diode, red light

Light dot0.008 mm²

With restart blockageNo

Suitable for safety functionsNo

Degree of protection (IP)IP67

Ambient temperature-10-50 °C

Rated control supply voltage DC10-30 V

Scope of delivery of the one-way systemTransmitter and receiver

Pre failure noticeNo

With time functionNo

Rated switching distance15000 mm

Max. switching distance20000 mm

Max. output current100 mA

With reflectorNo

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Ambient temperature-40-60 °C

Response time0.33 ms

Switching frequency1500 Hz

Rated control supply voltage DC10-30 V

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classNone

Wavelength of the sensor640 nm

Type of lightPolarity free red light

With restart blockageNo

Suitable for safety functionsNo

Degree of protection (IP)IP67

Scope of delivery of the one-way systemTransmitter and receiver

Pre failure noticeNo

With time functionNo

Rated switching distance60000 mm

Max. switching distance80000 mm

Max. output current100 mA

With reflectorNo

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15 mm

Height of sensor49 mm

Length of sensor41.5 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Ambient temperature-10-50 °C

Response time0.2 ms

Switching frequency2500 Hz

Rated control supply voltage DC10-30 V

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classClass 2

Wavelength of the sensor650 nm

Type of lightLaser diode, red light

With restart blockageNo

Suitable for safety functionsNo

Degree of protection (IP)IP67

Operating distance20-350 mm

Pre failure noticeNo

With time functionNo

Max. switching distance350 mm

Max. output current100 mA

With reflectorNo

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Response time0.33 ms

Switching frequency1500 Hz

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classNone

Wavelength of the sensor640 nm

Type of lightPolarity free red light

With restart blockageNo

Suitable for safety functionsNo

Degree of protection (IP)IP67

Ambient temperature-40-60 °C

Rated control supply voltage DC10-30 V

Operating distance80-850 mm

Pre failure noticeNo

With time functionNo

Max. switching distance850 mm

Max. output current100 mA

With reflectorNo

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureTeach-In

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP/NPN

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Response time0.2 ms

Switching frequency2500 Hz

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classClass 1

Wavelength of the sensor655 nm

Type of lightLaser diode, red light

With restart blockageNo

Suitable for safety functionsNo

Degree of protection (IP)IP67

Ambient temperature-40-60 °C

Rated control supply voltage DC10-30 V

Pre failure noticeNo

With time functionNo

Rated switching distance14000 mm

Max. switching distance18000 mm

Max. output current100 mA

With reflectorYes

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP/NPN

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15 mm

Height of sensor49 mm

Length of sensor41.5 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Ambient temperature-10-50 °C

Response time0.2 ms

Switching frequency2500 Hz

Rated control supply voltage DC10-30 V

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classClass 2

Wavelength of the sensor650 nm

Type of lightLaser diode, red light

Light dot0.5 mm²

Degree of protection (IP)IP67

Pre failure noticeNo

With time functionNo

Rated switching distance5000 mm

Max. switching distance7000 mm

Max. output current100 mA

With reflectorYes

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Ambient temperature-40-60 °C

Response time0.33 ms

Switching frequency1500 Hz

Rated control supply voltage DC10-30 V

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classNone

Wavelength of the sensor640 nm

Type of lightPolarity free red light

Degree of protection (IP)IP67

Pre failure noticeNo

With time functionNo

Rated switching distance5000 mm

Max. switching distance7000 mm

Max. output current100 mA

With reflectorYes

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureManual adjustment

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Ambient temperature-40-60 °C

Response time0.33 ms

Switching frequency1500 Hz

Rated control supply voltage DC10-30 V

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classNone

Wavelength of the sensor640 nm

Type of lightPolarity free red light

Degree of protection (IP)IP67

Pre failure noticeNo

With time functionNo

Rated switching distance800 mm

Max. switching distance800 mm

Max. output current100 mA

With reflectorYes

Analogue output 0 V ... 10 VNo

Analogue output 0 mA ... 20 mANo

Analogue output 4 mA ... 20 mANo

Analogue output -10 V ... +10 VNo

With other analogue outputNo

Setting procedureTeach-In

With communication interface analogueNo

With communication interface AS-InterfaceNo

With communication interface CANOpenNo

With communication interface DeviceNetNo

With communication interface EthernetNo

With communication interface INTERBUSNo

With communication interface PROFIBUSNo

With communication interface RS-232No

With communication interface RS-422No

With communication interface RS-485No

With communication interface SSDNo

With communication interface SSINo

Number of semiconductor outputs with signalling function1

Number of contact energized outputs with signalling function0

Number of protected semiconductor outputs1

Number of protected contact energized outputs0

Type of electric connectionConnector M12

Type of switching outputPNP

Operation agent-safety classSafety class 3

Explosion safety category for gasNone

Explosion safety category for dustNone

Construction type housingCuboid

Width sensor15.6 mm

Height of sensor48.5 mm

Length of sensor42 mm

Sensing modeLight-/dark switching

Material of optical surfacePlastic

Housing materialMetal

Max. output current at protected output100 mA

Ambient temperature-40-60 °C

Response time0.33 ms

Switching frequency1500 Hz

Rated control supply voltage DC10-30 V

Voltage typeDC

With monitoring function downstream switching devicesNo

Laser protection classNone

Wavelength of the sensor640 nm

Type of lightPolarity free red light

Degree of protection (IP)IP66

Built by rastro.ai
